Continued
** All contact closures must be maintained, except for speed search, which may
be momentary (see paragraph 5.19E).
14 ACC/DEC Switch Accel/decel time selection Open = Accel/decel by n018/ n019
Closed = Accel/decel by n020 / n021
See paragraph 5.2
15 Ext Baseblk (NO) External base block Closed = Shuts off drive output
(N.O. contact input) (frequency command is held)
16 Ext Baseblk (NC) External base block See paragraphs 5.19C, 5.19D
(N.C. contact input)
17
Spd Srch (MAXFRQ)
Speed Search 1 Closed * = Speed Search operation
from maximum frequency
See paragraph 5.19E
18 Spd Srch (SETFRQ) Speed Search 2 Closed * = Speed Search operation
from set frequency
See paragraph 5.19E
19 Param Lockout Programming enable Open = Programming from Digital
Operator or serial communication is
enabled
Closed = All programming is disabled
20 PID I Reset PID integral value reset Closed = Value of I (n087) is reset
to " 0 "
See paragraph 5.22I
21 PID Disable PID control disable Closed = PID control is disabled –
setpoint becomes frequency reference
See paragraph 5.22I
22 Timer Start Cmd Timer function See paragraph 5.19F
23 oH3 Input External overheat Closed = oH3 blinks on the Digital
Operator, and operation continues
(minor fault)
24 Ref Sample Hold Analog reference sample/hold Open = Hold frequency reference
Closed = Sample frequency reference
See paragraph 5.19G
25 KEB Cmd (NO) Inertia ride-thru command Closed = Inertia ride-thru is enabled
(N.O. contact input)
26 KEB Cmd (NC) Inertia ride-thru command Closed = Inertia ride-thru is disabled
(N.C. contact input)
27 Hold Command Accel/Decel Hold See paragraph 5.19 H
28 PID Polarity Sel PID Changeover See paragraph 5.19 I
29 Up/Down Control Up/Down function See paragraph 5.19 J (can only be
set in n040
5-30
Table 5-2. n036 thru n040 Data Settings - Continued
5.19 MULTI-FUNCTION INPUT TERMINALS (Term. S2-S6)
LED LCD
SETTING SETTING FUNCTION DESCRIPTION **
