7.5 d: Reference Settings
186 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
7.5 d: Reference Settings
â—† d1: Frequency Reference
No.
(Hex.)
Name Description
Default
(Range)
d1-01
(0280)
RUN
Reference 1 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection. 0.00 Hz
(0.00 - 400.00 Hz)
d1-02
(0281)
RUN
Reference 2 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-03
(0282)
RUN
Reference 3 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-04
(0283)
RUN
Reference 4 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-05
(0284)
RUN
Reference 5 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-06
(0285)
RUN
Reference 6 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-07
(0286)
RUN
Reference 7 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-08
(0287)
RUN
Reference 8 Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection]. 0.00 Hz
(0.00 - 400.00 Hz)
d1-17
(0292)
RUN
Jog Reference Sets the Jog frequency reference in the units from o1-03 [Frequency Display Unit Selection]. Set H1-
xx = 6 [MFDI Function Selection = Jog Reference Selection] to use the Jog frequency reference.
6.00 Hz
(0.00 - 400.00 Hz)
â—† d2: Reference Limits
No.
(Hex.)
Name Description
Default
(Range)
d2-01
(0289)
Frequency Reference Upper
Limit
Sets maximum limit for all frequency references. The maximum output frequency is 100%. 100.0%
(0.0 - 110.0%)
d2-02
(028A)
Frequency Reference Lower
Limit
Sets minimum limit for all frequency references. The maximum output frequency is 100%. 0.0%
(0.0 - 110.0%)
d2-03
(0293)
Analog Frequency Ref
Lower Limit
Sets the lower limit for the master frequency reference (the first frequency of the multi-step speed
reference) as a percentage. The maximum output frequency is 100%.
0.0%
(0.0 - 110.0%)
â—† d3: Jump Frequency
No.
(Hex.)
Name Description
Default
(Range)
d3-01
(0294)
Jump Frequency 1 Sets the median value of the frequency band that the drive will avoid. 0.0 Hz
(0.0 - 400.0 Hz)
d3-02
(0295)
Jump Frequency 2 Sets the median value of the frequency band that the drive will avoid. 0.0 Hz
(0.0 - 400.0 Hz)
d3-03
(0296)
Jump Frequency 3 Sets the median value of the frequency band that the drive will avoid. 0.0 Hz
(0.0 - 400.0 Hz)
d3-04
(0297)
Jump Frequency Width Sets the width of the frequency band that the drive will avoid. 1.0 Hz
(0.0 - 20.0 Hz)
