YASKAWA HV600

Parameter List
7
7.12 S: Special Applications
YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup 225
7.12 S: Special Applications
◆ S1: Dynamic Noise Control
No.
(Hex.)
Name Description
Default
(Range)
S1-01
(3200)
Dynamic Noise Control Sets the function that decreases the output voltage in variable torque applications to decrease audible
noise.
0 : Disabled
1 : Enabled
1
(0, 1)
S1-02
(3201)
Voltage Reduction Rate Sets the rate at which the drive will decrease the output voltage as a percentage of the V/f pattern
when operating with no load.
50.0%
(50.0 - 100.0%)
S1-03
(3202)
Voltage Restoration Level Sets the level at which the drive will start to restore the voltage as a percentage of the drive rated
torque.
20.0%
(0.0 - 90.0%)
S1-04
(3203)
Voltage Restoration Off
Level
Sets the level at which voltage restoration for the V/f pattern is complete as a percentage of the drive
rated torque. If the output is more than S1-04, the drive will control the voltage as specified by the V/
f pattern setting.
Note:
The lower limit of this parameter is the value of S1-03 [Voltage Restoration Level] + 10.0%.
50.0%
(10.0 - 100.0%)
S1-05
(3204)
Volt Restore Sensitivity
Time K
Sets the level of sensitivity of the output torque and LPF time constant for the voltage reduction rate.
You can adjust the level of sensitivity with the load response.
1.000 s
(0.000 - 3.000 s)
S1-06
(3205)
Volt Restore Impact Load
Time K
Sets the voltage restoration time constant when you add an impact load. 0.050 s
(0.000 - 1.000 s)
S1-07
(324C)
Output Phase Loss Level Decreases the output phase loss level when Dynamic Noise control is active. 100.0%
(10.0 - 100.0%)
◆ S2: Sequence Run Timers
No.
(Hex.)
Name Description
Default
(Range)
S2-01
(3206)
Timer 1 Start Time Sets the start time for timer 1.
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock],
default is 00:00. When o4-22 = 2 [12 Hour JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is
00:00 AM to 11:59 PM.
12:00
(12:00 AM - 11:59 PM)
S2-02
(3207)
Timer 1 Stop Time Sets the stop time for timer 1.
Note:
• Default is when o4-22 = 1 [Time Format = 12 Hour Clock]. When o4-22 = 0 [24 Hour Clock],
default is 00:00. When o4-22 = 2 [12 Hour JP Clock], default is 00:00 AM.
• Range is when o4-22 = 1. When o4-22 = 0, range is 00:00 to 24:00. When o4-22 = 2, range is
00:00 AM to 11:59 PM.
12:00
(12:00 AM - 11:59 PM)
S2-03
(3208)
Timer 1 Day Selection Sets the days for which sequence timer 1 is active.
0 : Timer Disabled
1 : Daily
2 : Mon - Fri
3 : Sat - Sun
4 : Monday
5 : Tuesday
6 : Wednesday
7 : Thursday
8 : Friday
9 : Saturday
10 : Sunday
0
(0 - 10)
S2-04
(3209)
Timer 1 Sequence Selection Sets the drive response when sequence timer 1 is active.
0 : Digital Out Only
1 : Run
2 : Run - PID Disable
0
(0 - 2)
