7.7 F: Options
192 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
No.
(Hex.)
Name Description
Default
(Range)
F7-20
(03F8)
EtherNet/IP Power Scaling
Factor
Sets the scaling factor for the power monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
F7-21
(03F9)
EtherNet/IP Voltage Scale
Factor
Sets the scaling factor for the voltage monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
F7-22
(03FA)
EtherNet/IP Time Scaling Sets the scaling factor for the time monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
F7-23
(03FB)
Dynamic Out Param 1 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0. When you use a ProfiNet option, set this parameter to set to configurable output
1.
0
F7-24
(03FC)
Dynamic Out Param 2 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0. When you use a ProfiNet option, set this parameter to set to configurable output
2.
0
F7-25
(03FD)
Dynamic Out Param 3 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0. When you use a ProfiNet option, set this parameter to set to configurable output
3.
0
F7-26
(03FE)
Dynamic Out Param 4 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0. When you use a ProfiNet option, set this parameter to set to configurable output
4.
0
F7-27
(03FF)
Dynamic Out Param 5 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0. When you use a ProfiNet option, set this parameter to set to configurable output
5.
0
F7-28
(0370)
Dynamic Out Param 6 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0.
0
F7-29
(0371)
Dynamic Out Param 7 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0.
0
F7-30
(0372)
Dynamic Out Param 8 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0.
0
F7-31
(0373)
Dynamic Out Param 9 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0.
0
F7-32
(0374)
Dynamic Out Param 10 for
CommCard
Sets Output Assembly 116 when you use an Ethernet/IP option. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0.
0
F7-33
(0375)
Dynamic In Param 1 for
CommCard
Sets Input Assembly 166 when you use an Ethernet/IP option. The drive sends the values from the
MEMOBUS/Modbus address registers stored for each parameter to Input Assembly 166. The drive
returns the default register value for the option card when the MEMOBUS/Modbus address is 0 and
the value sent to Input Assembly 166 is not defined. When you use a ProfiNet option, set this
parameter to set to configurable input 1.
0
F7-34
(0376)
Dynamic In Param 2 for
CommCard
Sets Input Assembly 166 when you use an Ethernet/IP option. The drive sends the values from the
MEMOBUS/Modbus address registers stored for each parameter to Input Assembly 166. The drive
returns the default register value for the option card when the MEMOBUS/Modbus address is 0 and
the value sent to Input Assembly 166 is not defined. When you use a ProfiNet option, set this
parameter to set to configurable input 2.
0
F7-35
(0377)
Dynamic In Param 3 for
CommCard
Sets Input Assembly 166 when you use an Ethernet/IP option. The drive sends the values from the
MEMOBUS/Modbus address registers stored for each parameter to Input Assembly 166. The drive
returns the default register value for the option card when the MEMOBUS/Modbus address is 0 and
the value sent to Input Assembly 166 is not defined. When you use a ProfiNet option, set this
parameter to set to configurable input 3.
0
F7-36
(0378)
Dynamic In Param 4 for
CommCard
Sets Input Assembly 166 when you use an Ethernet/IP option. The drive sends the values from the
MEMOBUS/Modbus address registers stored for each parameter to Input Assembly 166. The drive
returns the default register value for the option card when the MEMOBUS/Modbus address is 0 and
the value sent to Input Assembly 166 is not defined. When you use a ProfiNet option, set this
parameter to set to configurable input 4.
0
