YASKAWA HV600

7.14 Y: Application Features
236 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
No.
(Hex.)
Name Description
Default
(Range)
Y1-15
(3C0E)
RUN
Maximum Setpoint
Difference
Sets a percentage of difference between the setpoint and the feedback. The difference must be more
than this value for the time set in Y1-16 [Not Maintaining Setpoint Time] to trigger the drive response
set in Y1-17 [Not Maintaining Setpoint Sel].
Note:
• Unit and decimal place change when the system units change.
• If there is a fault, the drive will coast to a stop.
• Set this parameter to 0.0 to disable the function.
• This function is only active during run when in Auto Mode.
0.0%
(0.0 - 6000.0%)
Y1-16
(3C0F)
RUN
Not Maintaining Setpoint
Time
Sets the delay time before a Setpoint Not Met condition occurs. The drive must detect the setpoint
difference set in Y1-15 [Maximum Setpoint Difference] before the timer will start.
Note:
Set Y1-15 = 0 [Maximum Setpoint Difference = 0] to disable this function.
60 s
(0 - 3600 s)
Y1-17
(3C10)
Not Maintaining Setpoint Sel Sets the drive response when the feedback increases to more or decreases to less than the setpoint for
more than the amount set in Y1-15 [Maximum Setpoint Difference].
0 : Fault (and Digital Output)
1 : Alarm (and Digital Output)
2 : Digital Output Only
0
(0 - 2)
Y1-18
(3C11)
Prime Loss Detection
Method
Sets the units and quantity that the drive will use to determine LOP [Loss of Prime].
0 : Current (A)
1 : Power (kW)
2 : Torque (%)
0
(0 - 2)
Y1-19
(3C12)
RUN
Prime Loss Level Sets the level to detect the LOP [Loss of Prime] in the pump when in Auto or Sleep Boost Mode. 0.0
(0.0 - 1000.0)
Y1-20
(3C13)
RUN
Prime Loss Time Sets the delay time before the drive detects an LOP [Loss of Prime] condition. The timer starts when
the drive detects the conditions in Y1-18 [Prime Loss Detection Method] and Y1-19 [Prime Loss
Level].
20 s
(0 - 600 s)
Y1-21
(3C14)
Prime Loss Activation Freq Sets the frequency level above which the drive enables Loss of Prime detection. 0.0 Hz
(0.0 - 400.0)
Y1-22
(3C15)
Prime Loss Selection Sets the drive response when the drive is in the Loss of Prime condition.
0 : Fault (and Digital Output)
1 : Alarm (and Digital Output)
2 : Digital Output Only
0
(0 - 2)
Y1-23
(3C16)
Prime Loss Max Restart
Time
Sets the time in minutes that the drive will wait before it tries a restart after a restart fails or after it
does not do a restart because of a fault.
0.2 min
(0.2 - 6000.0 min)
Y1-40
(3C27)
RUN
Maximum Speed Sets the maximum speed.
Note:
This parameter is not effective when Y1-40 = 0.0 Hz or Y1-40 > E1-04 [Maximum Output
Frequency] × d2-01 [Frequency Reference Upper Limit].
0.0 Hz
(0.0 - 416.0)
◆ Y2: PID Sleep and Protection
No.
(Hex.)
Name Description
Default
(Range)
Y2-01
(3C64)
Sleep Level Type Sets the data source that the drive uses to know when to activate the Sleep Function.
0 : Output Frequency
1 : Output Current
2 : Feedback
3 : Output Speed (RPM)
5 : Output Frequency (non-PID)
Note:
• Feedback depends on PID direction operation.
• When the Sleep Function is active, the keypad will show the “Sleep” Alarm.
5
(0 - 5)
Y2-02
(3C65)
RUN
Sleep Level Sets the level that the level type set in Y2-01 [Sleep Level Type] must be at for the time set in Y2-03
[Sleep Delay Time] for the drive to enter Sleep Mode.
Note:
• When you set this parameter to 0.0, this function will not be active.
• This function is active only when the drive operates in AUTO Mode.
• When Y2-01 = 5 [Output Frequency (non-PID)], the drive will disable the Sleep function when
you set this parameter to 0.0.
• When Y2-01 ≠ 5, the drive will set the sleep level to the largest value from d2-02 [Frequency
Reference Lower Limit], Y1-06 [Minimum Speed], and Y4-12 [Thrust Frequency] when you set
this parameter to 0.0.
0.0
(0.0 - 6000.0)
