YASKAWA HV600 Installation & Startup

Parameter List
7
7.14 Y: Application Features
YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup 239
No.
(Hex.)
Name Description
Default
(Range)
Y4-42
(3D23)
Output Disconnect Detection
Sel
This parameter applies only when in Drive Mode. It sets the drive response if the connection between
the drive and the motor is disconnected.
0 : Disabled
1 : Alarm - Speed Search
2 : Alarm - Start at Zero
3 : Fault
Note:
1. Loss Of Load [Z1-31 to Z1-36], Load Verify [Z1-53], and Bypass Energy Savings [Z1-16]
can interfere with the correct operation of Output Disconnect Detection.
2. When the Output Disconnect is active, the drive internally disables Output Phase Loss
Detection of more than one phase.
0
(0 - 3)
Y4-43
(3D24)
Output Disconnect Inject
Current
Sets the level of DC injection current during output disconnect as a percentage of the drive rated
current.
30%
(5 - 50%)
◆ YA: Preset Setpoint
No.
(Hex.)
Name Description
Default
(Range)
YA-01
(3E58)
RUN
Setpoint 1 Sets the PID Setpoint when b1-01 = 0 [Frequency Reference Selection 1 = Keypad or Multi-Speed
Selection].
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display Scaling], and b5-
39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
YA-02
(3E59)
RUN
Setpoint 2 Sets the PID Setpoint as specified by the Multi-Setpoint digital inputs.
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display Scaling], and b5-
39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
YA-03
(3E5A)
RUN
Setpoint 3 Sets the PID Setpoint as specified by the Multi-Setpoint digital inputs.
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display Scaling], and b5-
39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
YA-04
(3E5B)
RUN
Setpoint 4 Sets the PID Setpoint as specified by the Multi-Setpoint digital inputs.
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display Scaling], and b5-
39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.00
(0.00 - 600.00)
◆ YC: Foldback Features
No.
(Hex.)
Name Description
Default
(Range)
YC-01
(3EBC)
Output Current Limit Select Sets the function to enable or disable the output current regulator.
0 : Disabled
1 : Enabled
0
(0, 1)
YC-02
(3EBD)
RUN
Current Limit Sets the current limit.
Note:
Value is internally limited to 300% of the drive rated current set in n9-01 [Inverter Rated
Current].
0.0 A
(0.0 - 1000.0 A)
◆ YF: PI Auxiliary Control
No.
(Hex.)
Name Description
Default
(Range)
YF-01
(3F50)
PI Aux Control Selection Sets the PI Auxiliary Control function.
0 : Disabled
1 : Enabled
0
(0, 1)
YF-02
(3F51)
RUN
PI Aux Control Transducer
Scale
Sets the full scale (10 V or 20 mA) output of the pressure transducer connected to the analog input
terminal programmed for H3-xx = 27 [PI Aux Control Feedback Level].
Note:
Parameters YF-21 [PI Aux Ctrl Level Unit Selection] and YF-22 [PI Aux Level Decimal Place
Pos] set the unit and resolution.
145.0
(1.0 - 6000.0)
