8.3 BACnet Communications
278 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
Object ID
Object Name
(Network Display, if
Different)
Modbus Reg. Precision Range Units PV Access
AV18 DC Bus Voltage 0031h XXXX.X 0-6553.5 V R
AV19 PI Feedback Level 0038h XXXX.X 0-100.0 % R
AV20 PI Input Level 0039h XXXX.X 0-100.0 % R
AV21 PI Output Level 003Ah XXXX.X 0-100.0 % R
AV22 Drive SW Num 004Dh XXXXX 0-65535 - R
AV23 Bypass SW Num 8791h XXXXX 0-65535 - R
AV24 Comm Error Detail 003Dh XXX 0-127 Bitmap R
AV25 KVA Setting 0508h XXXXX -
Enumerated Data
Vendor Specific
R
AV26 Control Method 0043h XXXXX -
Enumerated Data
Vendor Specific
R
AV27 Accel Time 0200h XXXX.X 0-6000.0 S W
AV28 Decel Time 0201h XXXX.X 0-6000.0 S W
AV29 Parameter Number
####h
Determined in runtime
XXXXX 0-65535 - W
AV30 Parameter Data
####h
Determined in runtime
XXXXX 0-65535 - W
AV31 Motor Current 8780h
XXXX.X > 11 kVA
XXX.XX <= 11 kVA
0-6553.5 > 11 kVA
0-655.35 <= 11 kVA
A R
AV32 120V to Kx Coils 8790h XXXXX 0-65535 V R
AV33
Drive kWh consumed
(kWh consumed)
005Ch -005Dh XXXXXXXXX 0-999999999 kWh R
AV34 Not Used AV34 - - - - R
AV35 Drive Run Time 004Ch XXXXX 0-65535 Hours R
AV36 Out Freq in % 003Fh XXX.XX 0-100.00 % R
AV37 Out Freq in RPM 003Eh XXXXX 0-65535 RPM R
AV38 Torque Iq (U6-01) 0051h XXXX.X 0-6553.5 % R
AV39 Drive HOA Status 004Bh X 0-2 - R
AV40
Last Drive Fault
Refer to page 100 for
information on fault
decimal values.
0081h XXXXX 0-65535 - R
AV41
Last Bypass Fault
Refer to page 100 for
information on fault
decimal values.
878Ch XXXXX 0-65535 - R
AV42
Current Sys Fault
(Current Sys Flt)
Refer to 100 for
information on fault
decimal values.
0080h XXXXX 0-65535 - R
■ Binary Input Objects
Object ID
Object Name
(Network Display, if
Different)
Modbus Reg. Active Text Inactive Text PV Access
BI1
Drive Input Terminal 1
(Input Terminal 1)
002Bh:bit 0 ON OFF R
BI2
Drive Input Terminal 2
(Input Terminal 2)
002Bh:bit 1 ON OFF R
BI3
Drive Input Terminal 3
(Input Terminal 3)
002Bh:bit 2 ON OFF R
