YASKAWA HV600

3.4 Main Circuit Terminal Wiring Procedure
46 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
A - Optional drive control wiring
B - Motor output circuit
C - Main input circuit
Figure 3.5 Narrow Bypass Wire Routing Example (Models H6BPD002 to D074 and B001 to B077)
A
C
B
