YASKAWA varispeed G7 CIMR-G7B series - Exterior and Mounting Dimensions

1-6
Exterior and Mounting Dimensions
 Open Chassis Inverters (IP00)
Exterior diagrams of the Open Chassis Inverters are shown below.
Fig 1.6 Exterior Diagrams of Open Chassis Inverters
W
W1
3
H1H2
D
H
D1
4-d
t1
6-d
t1
D1
D
W1
W1
W
W3
W2
H
H2 H1
200 V Class Inverters of 18.5 to 110 kW
400 V Class Inverters of 18.5 to 160 kW
W
W1
4-d
H2
(5)
D1
D
H1
H
t1
(5)*
(5)*
200 V/400 V Class Inverters of 0.4 to 15 kW
400 V Class Inverters of 185 to 300 kW
* (10) for 200 V Class Inverters of 30 to 110 kW or
400 V Class Inverters of 55 to 160 kW.
