Wiring Main Circuit Terminals
2-13
îš‹ Main Circuit Terminal Functions
Main circuit terminal functions are summarized according to terminal symbols in Table 2.4. Wire the terminals
correctly for the desired purposes.
Table 2.4 Main Circuit Terminal Functions (200 V Class and 400 V Class)
Note The 1 and input terminals for the DC power do not conform to UL/cUL standards.
Purpose Terminal Symbol
Model: CIMR-G7B
200 V Class 400 V Class
Main circuit power input
R/L1, S/L2, T/L3 20P4 to 2110 40P4 to 4300
R1/L11, S1/L21, T1/L31 2018 to 2110 4018 to 4300
Inverter outputs U/T1, V/T2, W/T3 20P4 to 2110 40P4 to 4300
DC power input
1,
20P4 to 2110 40P4 to 4300
Braking Resistor Unit connec-
tion
B1, B2 20P4 to 2015 40P4 to 4015
DC reactor connection
1, 2
20P4 to 2015 40P4 to 4015
Braking Unit connection
3,
2018 to 2110 4018 to 4300
Ground 20P4 to 2110 40P4 to 4300
To Next Page
