YASKAWA varispeed G7 CIMR-G7B series

User Constants
10-31
10
Table 10.7 User Constants (Continued)
C6-02 Carrier frequency selection
6
*6
C6-03
*8
Carrier frequency upper limit
15.0
*6
C6-04
*8
Carrier frequency lower limit
15.0
*6
C6-05
*8
Carrier frequency proportional
gain
00
C6-11
Carrier frequency for open-loop
vector 2 control
1
*6
d1-01 Frequency reference 1 0.00
d1-02 Frequency reference 2 0.00
d1-03 Frequency reference 3 0.00
d1-04 Frequency reference 4 0.00
d1-05 Frequency reference 5 0.00
d1-06 Frequency reference 6 0.00
d1-07 Frequency reference 7 0.00
d1-08 Frequency reference 8 0.00
d1-09 Frequency reference 9 0.00
d1-10 Frequency reference 10 0.00
d1-11 Frequency reference 11 0.00
d1-12 Frequency reference 12 0.00
d1-13 Frequency reference 13 0.00
d1-14 Frequency reference 14 0.00
d1-15 Frequency reference 15 0.00
d1-16 Frequency reference 16 0.00
d1-17 Jog frequency reference 6.00
d2-01 Frequency reference upper limit 100.0
d2-02 Frequency reference lower limit 0.0
d2-03 Master speed reference lower limit 0.0
No. Name
Fac-
tory
Setting
Set-
ting
d3-01 Jump frequency 1 0.0
d3-02 Jump frequency 2 0.0
d3-03 Jump frequency 3 0.0
d3-04 Jump frequency width 1.0
d4-01
Frequency reference hold function
selection
0
d4-02 + - Speed limits 10
d5-01 Torque control selection 0
d5-02 Torque reference delay time
0
*7
d5-03 Speed limit selection 1
d5-04 Speed limit 0
d5-05 Speed limit bias 10
d5-06
Speed/torque control switching
timer
0
d5-07
Rotation direction limit operation
selection
1
d6-01 Field weakening level 80
d6-02 Field frequency 0.0
d6-03 Field forcing function selection 0
d6-05 AφR time constant 1.00
d6-06 Field forcing limit 400
E1-01 Input voltage setting
200
*9
E1-03 V/f pattern selection F
E1-04 Max. output frequency
50.0
*2
E1-05 Max. voltage
200.0
*2 *9
E1-06 Base frequency
50.0
*2
E1-07 Mid. output frequency
3.0
*2
E1-08 Mid. output frequency voltage
13.2
*2 *9
No. Name
Fac-
tory
Setting
Set-
ting
