YASKAWA Z1000 Technical Manual

4.2 Using the HOA Keypad
Use the HOA keypad to enter OFF commands, switch AUTO or HAND Mode, change parameters, and display data including
fault and alarm information.
u
HOA Keypad and Control Panel Display
Drive/Bypass
and HOA
Keypad with
HAND/OFF/AUTO
Keys
Digital
Operator
Blank
Cover
Figure 4.1 Z1000 Bypass HOA Keypad
4.2 Using the HOA Keypad
YASKAWA ELECTRIC SIEP YAIZ1B 01E YASKAWA AC Drive – Z1000 Bypass Technical Manual
91
4
Start-Up Programming & Operation

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
