Yealink T22P Guide

Enterprise IP Phone Using the Advanced Phone Functions
- 63 -
Network Setting
PC Port Setting
Please refer to the previous part “Configuration and Registration” for the basic Network
WAN setting information. The following table lists the instructions of the field about the
Network PC Port Setting.
Field Name
Description
As Bridge
If you select the Bridge mode, then the two Fast Ethernet ports will
be transparent.
As Router
If you select the Router mode, the SIP phone will work as a router.
IP address
User could configure the PC port IP address.
DHCP Server
If you set the DHCP server on, the device connected to the PC port
will get the IP address automatically between the start IP address
and the end IP address. But if you select the bridge mode, the DHCP
server can not work.
Start IP Address
Indicate the range of the IP address.
End IP Address
Indicate the range of the IP address.

Yealink T22P Specifications

General

Protocol	SIP
Power over Ethernet	Yes (IEEE 802.3af)
Weight	0.77kg
Audio Features	Full-duplex speakerphone
Lines	3
Codecs	G.722, G.711
Standards Compliance	IEEE802.3af
Dimensions	209mm x 188mm x 150mm x 41mm
Headset Port	RJ9
