Yealink T22P Guide

Enterprise IP Phone Getting Started
- 3 -
Assembling the Phone
This section introduce how to assemble the phone with the components in the packing
list：
 Attach the stand;
 Connect Handset and Headset;
 Connect Network and Power.
1) Attach the Stand, as shown below:
Stand attached
2) Connect Handset and Headset, as shown below:
Note:
Headset is not provided in the packing list. Please contact your distributor for more
information.
3) Connect Network and Power
There are two ways for network and power source connections. You can either connect
the phone to the AC Power directly using the power adapter or to a PoE compliant
switch or hub. Your system administrator will advise you on which one to use.

Yealink T22P Specifications

General

Protocol	SIP
Power over Ethernet	Yes (IEEE 802.3af)
Weight	0.77kg
Audio Features	Full-duplex speakerphone
Lines	3
Codecs	G.722, G.711
Standards Compliance	IEEE802.3af
Dimensions	209mm x 188mm x 150mm x 41mm
Headset Port	RJ9
