Getting Started
25
Do the following:
1. Open the baffle.
2. Push the bracket along the track.
3. Remove the protection of the Velcro.
4. Put the L-bracket on the top of the TV.
5. Make sure the back of the TV is clean, and then adjust the bracket to ensure close adhesion
to the back of the TV with Velcro.
6. Lock the VC800 codec to the L-bracket with the M3×8 screws.
Mounting the VC800 Codec on a Wall
You can also decide to mount the VC800 codec on a wall. The recommended height for VC800
codec positioning is 1.5m-1.8m above the ground.
Do the following:
1. Punch holes into the wall and then insert the expansion bolts.
Installation location for the expansion bolts and punching requirement are shown above.
2. Drive screws.
3. Push the VC800 codec along the track of the bracket.
