10-10
IM AQ1210-01EN
• Operation on the Wireless Terminal
6.
Search for the access point from the wireless terminal, and connect to the access point. Check
that the SSID is the same as that of the instrument.
7.
Start OTDR Data Transporter on the wireless terminal. For the operating procedure of the
application, see the application software’s help.
Note
Only a single wireless terminal can access the instrument at any given time. (Multiple wireless terminals
cannot access the instrument simultaneously.)
Controlling the OTDR Remotely
Executing OTDR Remote Control (Access Point Standby State)
5.
Continuing from step 4 on page 10-6, tap OTDR Remote Controller. A standby screen appears
for OTDR remote control. An icon indicating that the wireless LAN is in use appears at the top
of the screen.
Cancels waveform data transfer
Access point information
An icon indicating that the wireless LAN is in use
If you execute the Stop WLAN function, the wireless LAN operation ends, and
the icon disappears.
If you select Back to OTDR, the wireless operation does not end, and the icon
remains displayed. In addition, even if you stop accessing from the wireless
terminal, the wireless LAN operation does not end, so you can access from the
wireless terminal again.
Returns to the previous screen
You can monitor the operation through
remote control or control the OTDR
10.4 Using the WLAN Application
