2-26
IM AQ1210-01EN
Setting the File Report Format
5.
Tap File Report Setup to display the Report Format screen.
Set the report format.
Event List preview
Automatically arranged according
to the on/off state of display items
Number waveforms to display (1Trace, 2Trace)
Select the number of waveforms to show in a single page.
You can select the following items only when 2Trace is
selected.
Order (File Name, Date, ID)
Select the file export order
(by file name, by date, by ID).
ID Position (Top, Bottom)
Set the ID position of the file name.
You can select this when the order is set to ID.
Sort Order
(A -> Z, Z -> A)
Selects the output
sort order
Event list display items ON/OFF
Set the items you want to display to ON.
Up to 5 items can be set to ON.
Preview of the order in
which files will be
exported.
2.4 File Conditions
To Next Page
