Attaching the Roll Paper
CAUTION
• Do not touch the print head. If you do, you may burn yourself.
• Do not touch the roll paper cutter section at the front end of the printer cover. Doing so may
cause injury.
French
ATTENTION
• Ne pas toucher la tête d’impression. Vous pourriez vous brûler.
• Ne pas toucher la section du coupe-papier à l’extrémité du cache de l’imprimante. Vous
pourriez vous blesser.
Roll paper cutter section
Print head
Raise the handle.
Printer cover
OPEN COVER
button
Press the OPEN COVER button to open
the printer cover.
Guide
Align the ends of the roll paper with
the guides, and set the roll in place.
Close the cover, and press LOCK on the
center of the cover until you hear a click.
Set the roll paper with
the same orientation
as shown in the figure.
5.
3.18 Loading Roll Paper into the Built-In Printer (Optional)
3-58
IM DL850E-03EN
To Next Page
