4-7
IM DL850E-03EN
Common Operations
4
Operating the DL850E/DL850EV Using a USB Mouse
• Operations That Correspond to the Front Panel Keys (Top Menu)
Displaying the Top Menu
Right-click on the display. A menu of the DL850E/DL850EV front panel keys appears.
Selecting an Item from the Top Menu
Click on the item that you want to select. A setup menu that corresponds to the item that you
selected appears at the bottom of the display. The top menu disappears.
To display an item’s submenu, point to the item. To select an item on a submenu, click on it, just
as you would to select an item on the top menu.
Pointer
Right-click to display the top menu.
Submenu
Submenus appear for items that have them.
The setup menu that you select
using the mouse appears.
Note
The following keys are not displayed in the top menu:
ESC, RESET, and SET
4.3 Using USB Keyboards and Mouse Devices
To Next Page
