Item Specifications
IIR:
Filter format: IIR (Butterworth)
Filter type: LPF, HPF, BPF
Filter order: 4
LPF: Cutoff frequency: 3 MHz to 0.2 Hz
Resolution: 3 MHz to 300 kHz, in steps of 20 kHz
Resolution: 298 kHz to 30 kHz, in steps of 2 kHz
Resolution: 29.8 kHz to 3 kHz, in steps of 200 Hz
Resolution: 2.98 kHz to 0.3 kHz, in steps of 20 Hz
Resolution: 298 Hz to 30 Hz, in steps of 2 Hz
Resolution: 29.8 Hz to 0.2 Hz, in steps of 0.2 Hz
HPF: Cutoff frequency: 3 MHz to 20 Hz
Resolution: 3 MHz to 300 kHz, in steps of 20 kHz
Resolution: 298 kHz to 30 kHz, in steps of 2 kHz
Resolution: 29.8 kHz to 3 kHz, in steps of 200 Hz
Resolution: 2.98 kHz to 20 Hz, in steps of 20 Hz
BPF: Center frequency: 3 MHz to 60 Hz
Resolution: 3 MHz to 120 kHz, in steps of 20 kHz
Resolution: 118 kHz to 12 kHz, in steps of 2 kHz
Resolution: 11.8 kHz to 1.2 kHz, in steps of 200 Hz
Resolution: 1.18 kHz to 60 Hz, in steps of 20 Hz
Bandwidth: 2 MHz, 1.5 MHz, 1 MHz, 500 kHz, 200 kHz,
150 kHz, 100 kHz, 50 kHz, 20 kHz, 15 kHz,
10 kHz, 5 kHz, 2 kHz, 1.5 kHz, 1 kHz, 500 Hz,
200 Hz, 100 Hz (there are limits based on the
center frequency)
Cutoff characteristic: –24 dB/Oct
Phase: Nonlinear phase characteristicst
Interpolation: Interpolation can be turned on and off.
Resolver:
The angle of rotation is computed from the carrier signal, sine signal, and cosine
signal.
Supported carrier frequencies: 1 kHz to 20 kHz
Tracking filter band setting: 2 kHz, 1 kHz, 250 Hz, 100 Hz
Maximum measurable angular acceleration:
140000 rps
2
(when the tracking filter is set to 2 kHz)
54000 rps
2
(when the tracking filter is set to 1 kHz)
1800 rps
2
(when the tracking filter is set to 250 Hz)
180 rps
2
(when the tracking filter is set to 100 Hz)
Demodulation of the pulse width modulated (PWM) signal:
The PWM-modulated signal is integrated over the modulation period and converted
into an analog signal.
Reactive power:
The reactive power is computed from apparent power and effective power.
CAN ID detection:
The frame of the CAN bus signal with the specified ID is detected.
Torque:
The torque is computed from the measured frequenvy and the specified coefficient.
Angle difference math:
S1 – S2 (Angle)
Subtract the value (angle) of source channel 2 from the value (angle) of source
channel 1.
3 Phase Resolver:
Calculates the angle of rotation from the two sine signals that are generated from the
detection coil of the 3 phase resolver depending on the angle of the rotor.
Supported carrier frequencies: 1 kHz to 20 kHz
Tracking filter band setting: 2 kHz, 1 kHz, 250 Hz, 100 Hz
6.5 Features
