YOKOGAWA DL850E User Manual

6-11
IM DL850E-03EN
Specifications
1
2
3
4
5
6
App
Index
Item Specifications
Rms math system Select true rms value or rectified mean value calibrated to the rms value
Math sync mode Edge: Select a signal. Computed using zero-crossings.
Auto Timer: Specify the time. Computed at specified time intervals.
AC: Select a signal. Computed using zero-crossings. Signal stop determined by a
stop prediction function.
AC+DC: Select a signal. Computed using zero-crossings. Signal stop determined by a
stop prediction function.
Switches to Auto Timer after stopping.
Channel selection for edge Select a single channel from own phase voltage, own phase current, or other voltage/current.
Sync channel filter If sync mode is set to Edge, low-pass filter can be selected.
Cutoff frequency: Select from 128 kHz, 64 kHz, 32 kHz, 16 kHz, 8 kHz, 4 kHz, 2 kHz, 1 kHz,
500 Hz, 250 Hz, 125 Hz, and 62.5 Hz.
Harmonic analysis
Max. number of analyzable
systems
1 system
Max. number of analyzable
frequencies
Fundamental wave 1 kHz
FFT points 512
Supported wiring systems Single-phase, two-wire (1P2W); single-phase, three-wire (1P3W); or three-phase, three-wire
(3P3W),
Three-phase, three wire system that uses a three-voltage, three-current method (3P3W;
3V3A); three-phase, four-wire system (3P4W)
Delta math function Three -phase, three-wire (3P3W) → three-phase, three wire system that uses a three-voltage,
three-current method (3P3W; 3V3A)
Three-phase, three-wire (3V3A) → three-phase, four-wire system (3P4W) (delta → star)
Three-phase, four-wire system (3P4W) → three-phase, three-wire (3V3A) (star → delta)
Math mode Rms analysis mode, power analysis mode
Math items Rms analysis mode:
Rms values of the 1st to 40th harmonic
Rms percentage content of the 1st to 40th harmonic
Phase angles of the 1st to 40th harmonic
Total rms value
Distortion factor (IEC)
Distortion factor (CSA)
Power analysis mode:
Active powers from the 1st to the 35th harmonic
Active power percentage content from the 1st to the 35th harmonic
Phase angles of the 1st to 35th harmonic
Total active powers
Total reactive powers
Total apparent powers
Power factor
1st harmonic rms voltage
1st harmonic rms current
1st harmonic voltage phase angle
1st harmonic current phase angle
Sync channel Rms analysis mode: Analysis source channel
Power analysis mode: Select one channel from voltage and current.
Sync channel filter Low-pass filter can be selected.
Cutoff frequency: Select from 128 kHz, 64 kHz, 32 kHz, 16 kHz, 8 kHz, 4 kHz, 2 kHz, 1 kHz,
500 Hz, 250 Hz, 125 Hz, and 62.5 Hz.
* If power math is not to be performed, the data on channels 13 to 16 are also applicable.
Example: If only harmonic analysis is to be performed, the data on channels 1 to 14 are applicable.
6.5 Features
