6.8 Storage
SD Memory Card
Item Specifications
Number of slots 1
Maximum capacity 32 GB
Supported cards SD and SDHC compliant memory cards
Internal HDD (/HD1 option)
Item Specifications
Number of drives 1
Size 2.5 in.
Available space 500 GB, FAT32
USB Storage Device
Item Specifications
Compatible USB storage
devices
Mass storage devices that are compliant with USB Mass Storage Class Ver. 1.1
Available space 2 TB
Partition style: MBR, Format: FAT32/FAT16
* See section 6.9, “USB Ports for Peripherals.”
External HDD Interface (/HD0 option)
Item Specifications
Connection interface eSATA
Number of drives 1
Available space 2 TB
Disk partition style: MBR, Format: FAT32
6.9 USB Ports for Peripherals
Item Specifications
Connector type USB type A (receptacle)
Electrical and mechanical
specifications
USB Rev. 2.0 compliant
Supported transfer mode HS (High Speed; 480 Mbps), FS (Full Speed; 12 Mbps), LS (Low Speed; 1.5 Mbps)
Compatible devices Mass storage devices that are compliant with USB Mass Storage Class Ver. 1.1
104 or 109 keyboards that are compliant with USB HID Class Version 1.1
Mouse devices that are compliant with USB HID Class Version 1.1
Number of ports 2
Power supply 5 V, 500 mA (for each port)
