YOKOGAWA DL850E User Manual

6-41
IM DL850E-03EN
Specifications
1
2
3
4
5
6
App
Index
Functional Specifications
Item Specifications
Deceleration prediction Computes the deceleration condition in realtime when the pulse input is cut off.
Can be specified when measuring the frequency, RPMs, RPSs, period, and velocity
Stop prediction Sets the frequency to 0 after a certain time elapses after the pulse input is cut off.
Stop interval setting: Set in the range of 1.5 to 10 times (10 settings) the period of the
pulse measured last
Can be specified when measuring the frequency, RPMs, RPSs, period, and velocity
Smoothing Computes the moving average of the measured data using the specified time
Specified time: 0.1 to 1000 ms (0.1 ms resolution)
Can be specified on all measurement parameters
Pulse average Performs frequency measurement per specified number of pulses. When fluctuation
exists periodically in the pulse interval, the fluctuation can be eliminated.
Specified number of pulses: 1 to 4096
Can be specified when measuring the frequency, RPMs, RPSs, power supply frequency,
period, pulse integration, and velocity
Offset function Observe fluctuation with respect to the offset frequency
Offset range:
Can be set up to 1000 times the maximum div value
• Frequency:
• RPMs:
• RPSs:
• Period:
• Duty cycle:
• Pulse width:
• Pulse integration:
• Velocity:
0 Hz to 500 kHz
0 rpm to 50 krpm
0 rps to 1000 rps
0 s to 50 s
0% to 100%
0 s to 50 s
−1.0000×10
22
to 1.0000×10
22
−1.0000×10
22
to 1.0000×10
22
6.13 Module Specifications
