Record Length
100 Mpoint 250 Mpoint 500 Mpoint 1 Gpoint 2 Gpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
6 s 1 M 60 M 2 M 120 M 5 M 300 M 10 M 600 M 20 M 1.2 G
8 s 1 M 80 M 2 M 160 M 5 M 400 M 10 M 800 M 20 M 1.6 G
10 s 1 M 100 M 2 M 200 M 5 M 500 M 10 M 1 G 20 M 2 G
20 s 500 k 100 M 1 M 200 M 2 M 400 M 5 M 1 G 10 M 2 G
30 s 200 k 60 M 500 k 150 M 1 M 300 M 2 M 600 M 5 M 1.5 G
1 min 100 k 60 M 200 k 120 M 500 k 300 M 1 M 600 M 2 M 1.2 G
2 min 50 k 60 M 200 k 240 M 200 k 240 M 500 k 600 M 1 M 1.2 G
3 min 50 k 90 M 100 k 180 M 200 k 360 M 500 k 900 M 1 M 1.8 G
4 min 20 k 48 M 100 k 240 M 200 k 480 M 200 k 480 M 500 k 1.2 G
5 min 20 k 60 M 50 k 150 M 100 k 300 M 200 k 600 M 500 k 1.5 G
6 min 20 k 72 M 50 k 180 M 100 k 360 M 200 k 720 M 500 k 1.8 G
7 min 20 k 84 M 50 k 210 M 100 k 420 M 200 k 840 M 200 k 840 M
8 min 20 k 96 M 50 k 240 M 100 k 480 M 200 k 960 M 200 k 960 M
9 min 10 k 54 M 20 k 108 M 50 k 270 M 100 k 540 M 200 k 1.08 G
10 min 10 k 60 M 20 k 120 M 50 k 300 M 100 k 600 M 200 k 1.2 G
12 min 10 k 72 M 20 k 144 M 50 k 360 M 100 k 720 M 200 k 1.44 G
15 min 10 k 90 M 20 k 180 M 50 k 450 M 100 k 900 M 200 k 1.8 G
30 min 5 k 90 M 10 k 180 M 20 k 360 M 50 k 900 M 100 k 1.8 G
1 h 2 k 72 M 5 k 180 M 10 k 360 M 20 k 720 M 50 k 1.8 G
2 h 1 k 72 M 2 k 144 M 5 k 360 M 10 k 720 M 20 k 1.44 G
3 h 500 54 M 2 k 216 M 2 k 216 M 5 k 540 M 10 k 1.08 G
4 h 500 72 M 1 k 144 M 2 k 288 M 5 k 720 M 10 k 1.44 G
5 h 500 90 M 1 k 180 M 2 k 360 M 5 k 900 M 10 k 1.8 G
6 h 200 43.2 M 1 k 216 M 2 k 432 M 2 k 432 M 5 k 1.08 G
7 h 200 50.4 M 500 126 M 1 k 252 M 2 k 504 M 5 k 1.26 G
8 h 200 57.6 M 500 144 M 1 k 288 M 2 k 576 M 5 k 1.44 G
9 h 200 64.8 M 500 162 M 1 k 324 M 2 k 648 M 5 k 1.62 G
10 h 200 72 M 500 180 M 1 k 360 M 2 k 720 M 5 k 1.8 G
12 h 200 86.4 M 500 216 M 1 k 432 M 2 k 864 M 2 k 864 M
1 day 100 86.4 M 200 172.8 M 500 432 M 1 k 864 M 2 k 1.728 G
2 days 50 86.4 M 100 172.8 M 200 345.6 M 500 864 M 1 k 1.728 G
3 days 20 51.84 M 50 129.6 M 100 259.2 M 200 518.4 M 500 1.296 G
4 days 20 69.12M 50 172.8M 100
345.6M 200 691.2M 500 1.728G
5 days 20 86.4M 50 216M 100 432M 200 864M 200 864M
6 days 10 51.84M 20 103.68M 50 259.2M 100 518.4M 200 1.0368G
8 days 10 69.12M 20 138.24M 50 345.6M 100 691.2M 200 1.3824G
10 days 10 86.4M 20 172.8M 50 432M 100 864M 200 1.728G
20 days 5 86.4M 10 172.8M 20 345.6M 50 864M 100 1.728G
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
