YOKOGAWA DL850E User Manual

App-10
IM DL850E-03EN
When the Record Length Is 2.5 Mpoint, 5 Mpoint, 10 Mpoint, 25 Mpoint, or 50 Mpoint
Record Length
2.5 Mpoint 5 Mpoint 10 Mpoint 25 Mpoint 50 Mpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
1 μs 10 M 100 10 M 100 10 M 100 10 M 100 10 M 100
2 μs 10 M 200 10 M 200 10 M 200 10 M 200 10 M 200
5 μs 10 M 500 10 M 500 10 M 500 10 M 500 10 M 500
10 μs 10 M 1 k 10 M 1 k 10 M 1 k 10 M 1 k 10 M 1 k
20 μs 10 M 2 k 10 M 2 k 10 M 2 k 10 M 2 k 10 M 2 k
50 μs 10 M 5 k 10 M 5 k 10 M 5 k 10 M 5 k 10 M 5 k
100 μs 10 M 10 k 10 M 10 k 10 M 10 k 10 M 10 k 10 M 10 k
200 μs 10 M 20 k 10 M 20 k 10 M 20 k 10 M 20 k 10 M 20 k
500 μs 10 M 50 k 10 M 50 k 10 M 50 k 10 M 50 k 10 M 50 k
1 ms 10 M 100 k 10 M 100 k 10 M 100 k 10 M 100 k 10 M 100 k
2 ms 10 M 200 k 10 M 200 k 10 M 200 k 10 M 200 k 10 M 200 k
5 ms 10 M 500 k 10 M 500 k 10 M 500 k 10 M 500 k 10 M 500 k
10 ms 10 M 1 M 10 M 1 M 10 M 1 M 10 M 1 M 10 M 1 M
20 ms 10 M 2 M 10 M 2 M 10 M 2 M 10 M 2 M 10 M 2 M
50 ms 5 M 2.5 M 10 M 5 M 10 M 5 M 10 M 5 M 10 M 5 M
100 ms 2 M 2 M 5 M 5 M 10 M 10 M 10 M 10 M 10 M 10 M
200 ms 1 M 2 M 2 M 4 M 5 M 10 M 10 M 20 M 10 M 20 M
500 ms 500 k 2.5 M 1 M 5 M 2 M 10 M 5 M 25 M 10 M 50 M
1 s 200 k 2 M 500 k 5 M 1 M 10 M 2 M 20 M 5 M 50 M
2 s 100 k 2 M 200 k 4 M 500 k 10 M 1 M 20 M 2 M 40 M
3 s 50 k 1.5 M 100 k 3 M 200 k 6 M 500 k 15 M 1 M 30 M
4 s 50 k 2 M 100 k 4 M 200 k 8 M 500 k 20 M 1 M 40 M
5 s 50 k 2.5 M 100 k 5 M 200 k 10 M 500 k 25 M 1 M 50 M
6 s 20 k 1.2 M 50 k 3 M 100 k 6 M 200 k 12 M 500 k 30 M
8 s 20 k 1.6 M 50 k 4 M 100 k 8 M 200 k 16 M 500 k 40 M
10 s 20 k 2 M 50 k 5 M 100 k 10 M 200 k 20 M 500 k 50 M
20 s 10 k 2 M 20 k 4 M 50 k 10 M 100 k 20 M 200 k 40 M
30 s 5 k 1.5 M 10 k 3 M 20 k 6 M 50 k 15 M 100 k 30 M
1 min 2 k 1.2 M 5 k 3 M 10 k 6 M 20 k 12 M 50 k 30 M
2 min 2 k 2.4 M 2 k 2.4 M 5 k 6 M 20 k 24 M 20 k 24 M
3 min 1 k 1.8 M 2 k 3.6 M 5 k 9 M 10 k 18 M 20 k 36 M
4 min 1 k 2.4 M 2 k 4.8 M 2 k 4.8 M 10 k 24 M 20 k 48 M
5 min 500 1.5 M 1 k 3 M 2 k
6 M 5 k 15 M 10 k 30 M
6 min 500 1.8 M 1 k 3.6 M 2 k 7.2 M 5 k 18 M 10 k 36 M
7 min 500 2.1 M 1 k 4.2 M 2 k 8.4 M 5 k 21 M 10 k 42 M
8 min 500 2.4 M 1 k 4.8 M 2 k 9.6 M 5 k 24 M 10 k 48 M
9 min 200 1.08 M 500 2.7 M 1 k 5.4 M 2 k 10.8 M 5 k 27 M
10 min 200 1.2 M 500 3 M 1 k 6 M 2 k 12 M 5 k 30 M
12 min 200 1.44 M 500 3.6 M 1 k 7.2 M 2 k 14.4 M 5 k 36 M
15 min 200 1.8 M 500 4.5 M 1 k 9 M 2 k 18 M 5 k 45 M
30 min 100 1.8 M 200 3.6 M 500 9 M 1 k 18 M 2 k 36 M
1 h 50 1.8 M 100 3.6 M 200 7.2 M 500 18 M 1 k 36 M
2 h 20 1.44 M 50 3.6 M 100 7.2 M 200 14.4 M 500 36 M
3 h 20 2.16 M 20 2.16 M 50 5.4 M 200 21.6 M 200 21.6 M
4 h 10 1.44 M 20 2.88 M 50 7.2 M 100 14.4 M 200 28.8 M
5 h 10 1.8 M 20 3.6 M 50 9 M 100 18 M 200 36 M
6 h 10 2.16 M 20 4.32 M 20 4.32 M 100 21.6 M 200 43.2 M
7 h 5 1.26 M 10 2.52 M 20 5.04 M 50 12.6 M 100 25.2 M
8 h 5 1.44 M 10 2.88 M 20 5.76 M 50 14.4 M 100 28.8 M
9 h 5 1.62 M 10 3.24 M 20 6.48 M 50 16.2 M 100 32.4 M
10 h 5 1.8 M 10 3.6 M 20 7.2 M 50 18 M 100 36 M
12 h 5 2.16 M 10 4.32 M 20 8.64 M 50 21.6 M 100 43.2 M
1 day 5 4.32 M 10 8.64 M 20 17.28 M 50 43.2 M
2 days 5 8.64 M 10 17.28 M 20 34.56 M
3 days 5 12.96 M 10 25.92 M
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
(Continued on next page)
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
