YOKOGAWA DL850E User Manual

App-13
IM DL850E-03EN
Appendix
1
2
3
4
5
6
App
Index
(Continued from previous page)
Record Length
100 Mpoint 250 Mpoint 500 Mpoint 1 Gpoint 2 Gpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
4 days 20 69.12M 50 172.8M 100 345.6M 200 691.2M 500 1.728G
5 days 20 86.4M 50 216M 100 432M 200 864M 200 864M
6 days 10 51.84M 20 103.68M 50 259.2M 100 518.4M 200 1.0368G
8 days 10 69.12M 20 138.24M 50 345.6M 100 691.2M 200 1.3824G
10 days 10 86.4M 20 172.8M 50 432M 100 864M 200 1.728G
20 days 5 86.4M 10 172.8M 20 345.6M 50 864M 100 1.728G
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
