Maximum Number of History Waveform Acquisitions
The maximum number of acquisitions varies for each module as indicated below.
Model
Record Length Standard /M1 (1 G) /M2 (2 G)
1 k 5000 5000 5000
2.5 k 5000 5000 5000
5 k 2976 5000 5000
10 k 1487 5000 5000
25 k 593 2381 5000
50 k 295 1189 2381
100 k 144 583 1168
250 k 57 236 474
500 k 28 116 235
1 M 13 54 111
2.5 M 4 22 46
5 M 1 10 22
10 M 1 4 10
25 M 1
1
1 3
50 M 1
2
1 1
100 M 1
3
1
1
1
250 M 1
4
1
2
1
1
500 M 0 1
3
1
2
1 G 0 1
4
1
3
2 G 0 0 1
4
Unit of record length: Point
1 When there are eight displayed channels
2 When there are four displayed channels
3 When there are two displayed channels
4 When there is one displayed channel
Maximum Sample Rate at Which Hard Disk Recording Is Possible
The maximum sample rate varies as indicated below depending on the number of channels that are
recorded.
Maximum Number of Channels Maximum Sample Rate
16 channels 100 kS/s
8 channels 200 kS/s
3 channels 500 kS/s
1 channel 1 MS/s
Appendix 3 Relationship between the Record Length and the Acquisition Mode
