App-26
IM DL850E-03EN
Operation Key
Soft Key
Setting
T
ime
Absolute T
ime
Current date and
time
Result Window
Zoom1
PRINT MENU
Print T
o
Builtin
UTILITY
System Config
Date/T
ime
Display
ON
Format
Y
ear/Month/Day
T
ime Synchro
T
ime Synchro
OFF
IRIG Format
A
Modulation
AM
Impedance
50
Language
Menu
English
Message
English
LCD
Auto OFF
OFF
Auto OFF Time
1 min
Brightness
3
Storage Manager
Media
HD
USB Keyboard
English
USB Function
TMC
Remote Ctrl
Device
USB
USB Function
TMC
Network
TCP/IP
DHCP
ON
DNS
Auto
FTP/Web Server
User Name
anonymous
T
imeOut(s)
1800
T
imeOut (s)
15
Mail
Attached Image File
OFF
T
imeOut (s)
15
Net Print
LPR Name
P
ASSTHRU
T
imeOut (s)
15
Net Drive
LoginName
anonymous
Passive
ON
T
imeOut (s)
1800
SNTP
T
imeOut (s)
3
Adjust at PowerON
OFF
Appendix 4 Default V
alues
Operation Key
Soft Key
Setting
Preference
Power
On Action
Start
OFF
Action
OFF
Logic Setup
Numerical Format
Bit
Cursor Order
1 -> 8
Bit Order
1 -> 8
T
erminal Setup
Remote Stop
On
T
rigger Out
Normal
Pulse Width
1 msec
Display Setup
Menu Font Size
Large
Base Color
Blue
Scale Font Size
Large
Scale On Item
All
Level Indicator
On
Horozontal Axis
Display Mode
Auto
Intensity
Grid
2
Cursor
8
Marker
8
Key/Knob Setup
Click Sound
ON
ST
ART/STOP
Response T
ime
Quick
Key Protect
T
ype
All
Release T
ype
Key
Analysis Setup
Cursor Read Mode
Display
Action Folder Mode
ON
Input Setup DC Offset
& Adjust
OFF
Self T
est
Keyboard
216
218
Table of Contents
Default Chapter
1
Getting Started Guide
1
Product Registration
2
List of Manuals
3
Regarding the Conventional DL850 and DL850V
5
Checking the Contents of the Package
6
Standard Accessories
8
Safety Precautions
15
Sales in each Country or Region
20
Symbols and Notation Used in this Manual
21
Table of Contents
22
Chapter 1 Names and Functions of Parts
25
Top Panel, Front Panel, Right Side Panel, and Left Side Panel
25
Universal (Voltage/Temp.)
27
Vent
29
Panel Keys and Knobs
31
Shift Key
34
Screens
35
System Configuration
37
Chapter 2 Main Features
38
Vertical and Horizontal Axes
38
Triggering
41
Waveform Acquisition
44
Hard Disk Recording
45
Waveform Display
47
Waveform Computation and Analysis
48
Chapter 3 Making Preparations for Measurements
50
Handling Precautions
50
Installing the Instrument
52
Installing Input Modules
55
Connecting to a Power Supply and Turning the Power Switch on and off
60
Connecting the Power Cord
61
Connecting Probes
66
Correcting the Probe Phase
77
Connecting Measurement Leads
79
Connecting Thermocouples
83
Connecting Bridgeheads
85
Connecting a Logic Probe to the Logic Input Module
88
3.11 Connecting an Acceleration Sensor
91
3.12 Connecting Sensors to the Frequency Module
94
Connecting Wires to the 16-CH Voltage Input Module
96
Connecting Wires to the 16-CH Temperature/Voltage Input Module
99
Connecting a Cable to the CAN Bus Monitor Module
103
Connecting a Cable to the CAN & LIN Bus Monitor Module
104
3.17 Attaching the Panel Sheet
105
Loading Roll Paper into the Built-In Printer (Option)
106
Connecting an Antenna to the GPS Interface (Option)
108
Chapter 4 Common Operations
109
Key and Jog Shuttle Operations
109
Entering Values and Strings
111
Using USB Keyboards and Mouse Devices
113
Connection Procedure
114
Synchronizing the Clock
118
Performing Auto Setup
119
Initializing Settings
121
Setup Menu
121
Calibrating the DL850E/DL850EV
122
Starting and Stopping Waveform Acquisition
123
Displaying Help
124
Chapter 5 External Signal I/O
125
External Trigger Input (TRIGGER IN)
125
Trigger Output (TRIGGER OUT)
126
External Clock Input (EXT CLK IN)
128
Video Signal Output (VIDEO out (XGA))
129
GO/NO-GO Determination I/O and External Start/Stop Input (EXT I/O)
130
IRIG Signal Input (IRIG Option)
134
GPS Signal Input (GPS Option)
135
Chapter 6 Specifications
136
Signal Input Section
136
Triggering Section
136
Time Axis
138
Display
138
Features
139
Data Storage
140
Fft
147
Built-In Printer
147
6.10 Auxiliary I/O Section
149
6.11 Computer Interface
151
6.12 General Specifications
152
Index
152
6.13 Module Specifications
156
High-Speed 10 Ms/S, 12-Bit Isolation Module (701250)
156
High-Speed High-Resolution 1 Ms/S, 16-Bit Isolation Module (701251)
158
High-Speed 10 Ms/S, 12-Bit Non-Isolation Module (701255)
160
High-Voltage 100 Ks/S, 16-Bit Isolation Module (with RMS) (701267)
161
Universal (Voltage/Temp.) Module (701261) / Universal (Voltage/Temp.) Module (with AAF) (701262)
163
Temperature, High Precision Voltage Isolation Module (701265)
165
Strain Module (NDIS) (701270)
167
Acceleration/Voltage Module (with AAF) (701275)
171
Frequency Module (701281)
173
High-Speed 100 Ms/S, 12-Bit Isolation Module (720210 and 720211)
177
16-CH Voltage Input Module (720220)
179
16-CH Temperature/Voltage Input Module (720221)
180
Logic Input Module (720230)
182
CAN Bus Monitor Module (720240)
183
CAN & LIN Bus Monitor Module (720241)
184
SENT Monitor Module (720243)
185
4-CH 1 Ms/S, 16-Bit Isolation Module (720254)
186
6.14 Logic Probe Specifications
188
16-CH Scanner Box Specifications
190
External Dimensions
190
External Dimensions
191
Appendix
192
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
193
Appendix
207
Relationship between the Main Channel Sample Rate, Sub Channel Data Update Rate, and Acquisition Memory Writing Rate
207
Appendix 3 Relationship between the Record Length and the Acquisition Mode
210
Appendix 4 Default Values
213
Appendix 5 USB Keyboard Key Assignments
219
Appendix 6 Block Diagrams
220
Appendix 7 High-Voltage 100 Ks/S, 16-Bit Isolation Module (with RMS) (701260) Specifications
223
Appendix 8 Frequency Module (701280) Specifications
225
