YOKOGAWA DL850E User Manual

1-4
IM DL850E-03EN
CAN & LIN Bus Monitor Module
CAN & LIN (model: 720241)
Strain Module (NDIS)
STRAIN_NDIS (model: 701270)
Strain Module (DSUB, Shunt-Cal)
STRAIN_DSUB (model: 701271)
Acceleration/Voltage Module
(with AAF)
ACCL/VOLT (model: 701275)
Frequency Module
FREQ (model: 701281)
High-Speed 100 MS/s,
12-Bit Isolation Module
HS100M12 (model: 720210 and 720211)
16-CH Voltage Input Module
16CH VOLT (model: 720220)
CAN Bus Monitor Module
CAN MONITOR (model: 720240)
Logic Input Module
LOGIC (model: 720230)
16-CH Temperature/Voltage
Input Module
16CH TEMP/VOLT (model: 720221)
4-CH 1 MS/s, 16-Bit Isolation
Module
4CH
1M16 (model: 720254)
SENT Monitor Module
SENT (model: 720243)
Temperature, High Precision
Voltage Isolation Module
TEMP/HPV (model: 701265)
H input terminal
L input terminal
(2ch)
Signal input
terminal (2ch)
Signal input
terminal (2ch)
Signal input
terminal (2ch)
Signal input
terminal (2ch)
Signal input
terminal (2ch)
Signal input
terminal (16ch)
CAN bus signal
input terminal
Logic probe
terminals
Signal input
terminal (16ch)
CAN bus signal
input terminal
LIN bus signal
input terminal
SENT signal
input terminal
Signal input
terminal (4ch)
1.1 Top Panel, Front Panel, Right Side Panel, and Left Side Panel
