5-2
IM 701310-17E
Command Function Page
:ANALysis:AHIStogram<x>:
MEASure:CURSor:HPOSition<x>
Sets the horizontal cursor position of the accumulated histogram or queries
the current setting.
5-38
:ANALysis:AHIStogram<x>:
MEASure:CURSor:VLINkage
Turns ON/OFF the vertical cursor link of the accumulated histogram or
queries the current setting.
5-38
:ANALysis:AHIStogram<x>:
MEASure:CURSor:VPOSition<x>
Sets the vertical cursor position of the accumulated histogram or queries the
current setting.
5-39
:ANALysis:AHIStogram<x>:
MEASure:MODE
Sets the automated measurement mode of the accumulated histogram or
queries the current setting.
5-39
:ANALysis:AHIStogram<x>:
MEASure:PARameter?
Queries all settings related to the automated measurement of waveform
parameters of the accumulated histogram.
5-39
:ANALysis:AHIStogram<x>:
MEASure:PARameter:AREA<x>?
Queries all settings related to the area of the accumulated histogram. 5-40
:ANALysis:AHIStogram<x>:
MEASure:PARameter:AREA<x>:ALL
Turns ON/OFF all waveform parameters of the accumulated histogram. 5-40
:ANALysis:AHIStogram<x>:
MEASure:PARameter:
AREA<x>:<Parameter>?
Queries all settings related to the waveform parameter of the accumulated
histogram.
5-40
:ANALysis:AHIStogram<x>:
MEASure:PARameter:
AREA<x>:<Parameter>:STATe
Turns ON/OFF the waveform parameter of the accumulated histogram or
queries the current setting.
5-40
:ANALysis:AHIStogram<x>:
MEASure:PARameter:
AREA<x>:<Parameter>:VALue?
Queries the automated measured value of the waveform parameter of the
accumulated histogram.
5-41
:ANALysis:AHIStogram<x>:
MEASure:PARameter:CALCulation?
Queries all settings related to the calculation items of waveform parameters
of the accumulated histogram.
5-41
:ANALysis:AHIStogram<x>:
MEASure:PARameter:CALCulation:
ALL
Turns ON/OFF all calculation items of the waveform parameters of the
accumulated histogram.
5-41
:ANALysis:AHIStogram<x>:
MEASure:PARameter:CALCulation:
DEFine<x>
Sets the equation of the calculation items of the waveform parameter of the
accumulated histogram or queries the current setting.
5-41
:ANALysis:AHIStogram<x>:
MEASure:PARameter:CALCulation:
STATe<x>
Turns ON/OFF the calculation items of the waveform parameter of the
accumulated histogram or queries the current setting.
5-41
:ANALysis:AHIStogram<x>:
MEASure:PARameter:CALCulation:
VALue<x>?
Queries the automated measured value of the calculation items of the
waveform parameter of the accumulated histogram.
5-41
:ANALysis:AHIStogram<x>:
MEASure:PARameter:HRANge<x>
Sets the horizontal range of the waveform parameter of the accumulated
histogram or queries the current setting.
5-42
:ANALysis:AHIStogram<x>:
MEASure:PARameter:VRANge<x>
Sets the vertical range of the waveform parameter of the accumulated
histogram or queries the current setting.
5-42
:ANALysis:AHIStogram<x>:MODE
Sets the accumulated histogram mode or queries the current setting. 5-42
:ANALysis:AHIStogram<x>:TRACe
Sets the source trace of the accumulated histogram or queries the current
setting.
5-42
:ANALysis:AHIStogram<x>:
VERTical
Sets the vertical range of the accumulated histogram or queries the current
setting.
5-42
:ANALysis:AHIStogram<x>:WINDow
Sets the measurement target window of the accumulated histogram or
queries the current setting.
5-42
:ANALysis:DISPlay<x>
Turns ON/OFF the analysis function display or queries the current setting. 5-42
:ANALysis:FFT<x>?
Queries all settings related to the FFT computation function. 5-43
:ANALysis:FFT<x>:HORizontal?
Queries all settings related the horizontal axis of the FFT computation. 5-43
:ANALysis:FFT<x>:HORizontal:
CSPan?
Queries all settings related to the center and span of the horizontal axis of
the FFT computation.
5-43
:ANALysis:FFT<x>:HORizontal:
CSPan:CENTer
Sets the horizontal center of the FFT computation or queries the current
setting.
5-43
:ANALysis:FFT<x>:HORizontal:
CSPan:SPAN
Sets the horizontal span of the FFT computation or queries the current
setting.
5-43
:ANALysis:FFT<x>:HORizontal:
LRIGht?
Queries all settings related the left and right edges of the horizontal axis of
the FFT computation.
5-43
:ANALysis:FFT<x>:HORizontal:
LRIGht:RANGe
Sets the range of the horizontal left and right edges of the FFT computation
or queries the current setting.
5-44
:ANALysis:FFT<x>:HORizontal:
MODE
Sets the horizontal mode of the FFT computation or queries the current
setting.
5-44
:ANALysis:FFT<x>:IPARt (Imag
Part)
Sets the source trace of the imaginary part of the FFT computation or queries
the current setting.
5-44
5.1 List of Commands
