Command Function Page
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor?
Queries all settings related to the cursor measurement of the trend of the
waveform parameter measurement.
5-58
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:ALL
Turns ON/OFF all cursors of the trend of the waveform parameter
measurement.
5-58
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:C<x>?
Queries all settings related to the measured value of the cursor of the trend
of the waveform parameter measurement.
5-58
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:C<x>:POSition
Sets the cursor position of the trend of the waveform parameter
measurement or queries the current setting.
5-59
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:C<x>:STATe
Turns ON/OFF the cursor of the trend of the waveform parameter
measurement or queries the current setting.
5-59
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:C<x>:VALue?
Queries the measured value of the cursor of the trend of the waveform
parameter measurement.
5-59
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:DC?
Queries all settings related to the measurement between cursors on the
trend of the waveform parameter measurement.
5-59
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:DC:STATe
Turns ON/OFF the measurement between cursors on the trend of the
waveform parameter measurement or queries the current setting.
5-59
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:DC:VALue?
Sets the measured value between cursors on the trend of the waveform
parameter measurement or queries the current setting.
5-59
:ANALysis:WPARameter<x>:TRENd:
MEASure:CURSor:LINKage
Turns ON/OFF the trend cursor link of the waveform parameter measurement
or queries the current setting.
5-60
:ANALysis:WPARameter<x>:TRENd:
MEASure:MODE
Sets the automated measurement mode of the trend of the waveform
parameter measurement or queries the current setting.
5-60
:ANALysis:WPARameter<x>:TRENd:
VERTical
Sets the vertical range of the trend of the waveform parameter measurement
or queries the current setting.
5-60
:ANALysis:XY<x>?
Queries all settings related to the XY display function. 5-60
:ANALysis:XY<x>:GATE?
Queries all settings related to the gate function of the XY display. 5-60
:ANALysis:XY<x>:GATE:ALEVel
Sets the active level of the gate of the XY display or queries the current
setting.
5-61
:ANALysis:XY<x>:GATE:
HYSTeresis<x>
Sets the hysteresis of the gate of the XY display or queries the current
setting.
5-61
:ANALysis:XY<x>:GATE:LEVel<x>
Sets the level of the gate of the XY display or queries the current setting. 5-61
:ANALysis:XY<x>:GATE:TRACe
Sets the gate trace of the XY display or queries the current setting. 5-61
:ANALysis:XY<x>:MEASure?
Queries all settings related to the automated measurement of the XY display. 5-61
:ANALysis:XY<x>:MEASure:CURSor?
Queries all settings related to the cursor measurement of the XY display. 5-61
:ANALysis:XY<x>:MEASure:CURSor:
XLINkage
Turns ON/OFF the horizontal cursor link on the XY display or queries the
current setting.
5-62
:ANALysis:XY<x>:MEASure:CURSor:
X<x>?
Queries all settings related to the horizontal cursor of the XY display. 5-62
:ANALysis:XY<x>:MEASure:CURSor:
X<x>:POSition
Sets the horizontal cursor position of the XY display or queries the current
setting.
5-62
:ANALysis:XY<x>:MEASure:CURSor:
X<x>:VALue?
Queries the voltage value at the horizontal cursor of the XY display. 5-62
:ANALysis:XY<x>:MEASure:CURSor:
YLINkage
Turns ON/OFF the vertical cursor link on the XY display or queries the
current setting.
5-62
:ANALysis:XY<x>:MEASure:CURSor:
Y<x>?
Queries all settings related to the vertical cursor of the XY display. 5-62
:ANALysis:XY<x>:MEASure:CURSor:
Y<x>:POSition
Sets the vertical cursor position of the XY display or queries the current
setting.
5-62
:ANALysis:XY<x>:MEASure:CURSor:
Y<x>:VALue?
Queries the voltage value at the vertical cursor of the XY display. 5-63
:ANALysis:XY<x>:MEASure:MODE
Sets the automated measurement mode of the XY display or queries the
current setting.
5-63
:ANALysis:XY<x>:MEASure:
XYINteg?
Queries all settings related to the integration of the XY display. 5-63
:ANALysis:XY<x>:MEASure:
XYINteg:LOOP
Sets the integration mode of the XY display or queries the current setting. 5-63
:ANALysis:XY<x>:MEASure:
XYINteg:POLarity
Sets the integration polarity of the XY display or queries the current setting. 5-63
:ANALysis:XY<x>:MEASure:
XYINteg:VALue?
Queries the integral value of the XY display. 5-63
:ANALysis:XY<x>:TRANge (Time
Range)
Sets the measurement range of the XY display or queries the current setting. 5-63
:ANALysis:XY<x>:WINDow
Sets the measurement source window of the XY display or queries the
current setting.
5-63
5.1 List of Commands
To Next Page
