YOKOGAWA DLM4038 User Manual

5-2
IM DLM4038-17EN
Command Function Page
:ANALysis:PANalyze<x>:HARMonics
:CLASs
Sets or queries the class of the device under harmonic analysis. 5-64
:ANALysis:PANalyze<x>:HARMonics
:DCLass?
Queries all class D harmonic analysis settings. 5-64
:ANALysis:PANalyze<x>:HARMonics
:DCLass:POWer
Sets or queries the power value for class D harmonic analysis. 5-64
:ANALysis:PANalyze<x>:HARMonics
:DETail?
Queries all harmonic analysis result list settings. 5-65
:ANALysis:PANalyze<x>:HARMonics
:DETail:DISPlay
Sets or queries the display position of the analysis result list of harmonic
analysis.
5-65
:ANALysis:PANalyze<x>:HARMonics
:DETail:LIST:ITEM?
Queries the items displayed in the harmonic analysis result list. 5-65
:ANALysis:PANalyze<x>:HARMonics
:DETail:LIST:VALue?
Queries all of the data for the specified analysis number in the harmonic
analysis result list.
5-65
:ANALysis:PANalyze<x>:HARMonics
:DMODe
Sets or queries the harmonic analysis display mode. 5-65
:ANALysis:PANalyze<x>:HARMonics
:GROuping
Sets or queries the harmonic analysis grouping. 5-65
:ANALysis:PANalyze<x>:HARMonics
:SPOint
Sets or queries the harmonic analysis computation start point. 5-65
:ANALysis:PANalyze<x>:HARMonics
:SVOLtage
Sets or queries the power supply voltage for harmonic analysis. 5-66
:ANALysis:PANalyze<x>:I2T?
Queries all Joule integral settings. 5-66
:ANALysis:PANalyze<x>:I2T:MATH
Sets or queries the on/off status of the Joule integral waveform display. 5-66
:ANALysis:PANalyze<x>:I2T:MEASu
re?
Queries all Joule integral automatic measurement settings. 5-66
:ANALysis:PANalyze<x>:I2T:MEASu
re:I2T?
Queries Joule integral settings. 5-66
:ANALysis:PANalyze<x>:I2T:MEASu
re:I2T:COUNt?
Queries the normal statistical processing count of the Joule integral. 5-66
:ANALysis:PANalyze<x>:I2T:MEASu
re:I2T:{MAXimum|MEAN|MINimum|SD
EViation}?
Queries a statistical value of a Joule integral. 5-66
:ANALysis:PANalyze<x>:I2T:MEASu
re:I2T:STATe
Sets or queries whether or not a Joule integral will be measured. 5-66
:ANALysis:PANalyze<x>:I2T:MEASu
re:I2T:VALue?
Queries an automatically measured value of a Joule integral. 5-67
:ANALysis:PANalyze<x>:I2T:RANGe
Sets or queries the measurement source window. 5-67
:ANALysis:PANalyze<x>:I2T:SCA
Le?
Queries all scaling settings. 5-67
:ANALysis:PANalyze<x>:I2T:SCALe
:CENTer
Sets or queries the center value for manual scaling. 5-67
:ANALysis:PANalyze<x>:I2T:SCALe
:MODE
Sets or queries the scaling mode. 5-67
:ANALysis:PANalyze<x>:I2T:SCALe
:SENSitivity
Sets or queries the sensitivity of the center position for manual scaling. 5-67
:ANALysis:PANalyze<x>:I2T:TRAN
ge (Time Range)
Sets or queries the measurement time period. 5-67
:ANALysis:PANalyze<x>:SETup?
Queries all power supply analysis input settings. 5-68
:ANALysis:PANalyze<x>:SETup:ADE
Skew
Executes automatic deskewing for power supply analysis. 5-68
:ANALysis:PANalyze<x>:SETup:I?
Queries all current input channel settings for power supply analysis. 5-68
:ANALysis:PANalyze<x>:SETup:I:D
ESKew
Sets or queries the deskew setting of the current input channel for power
supply analysis.
5-68
:ANALysis:PANalyze<x>:SETup:I:I
NPut
Sets or queries the current input channel for power supply analysis. 5-68
:ANALysis:PANalyze<x>:SETup:I:P
ROBe
Queries all current-to-voltage conversion ratio settings for the current input
channel probe for power supply analysis.
5-68
:ANALysis:PANalyze<x>:SETup:U?
Queries all voltage input channel settings for power supply analysis. 5-68
:ANALysis:PANalyze<x>:SETup:U:D
ESKew
Sets or queries the deskew setting of the voltage input channel for power
supply analysis.
5-68
:ANALysis:PANalyze<x>:SETup:U:I
NPut
Sets or queries the voltage input channel for power supply analysis. 5-68
5.1 List of Commands
