Command Function Page
:ANALysis:PANalyze<x>:SETup:U:P
ROBe
Sets or queries the probe attenuation setting of the voltage input channel for
power supply analysis.
5-69
:ANALysis:PANalyze<x>:SETup:RTR
ace
Sets or queries the reference trace for power supply analysis deskewing. 5-69
:ANALysis:PANalyze<x>:SOA?
Queries all XY display (safe operating area) settings. 5-69
:ANALysis:PANalyze<x>:SOA:CURS
or?
Queries all XY display (safe operating area) cursor measurement settings. 5-69
:ANALysis:PANalyze<x>:SOA:CURSo
r:X<y>?
Queries all XY display (safe operating area) horizontal cursor settings. 5-69
:ANALysis:PANalyze<x>:SOA:CURSo
r:X<y>:POSition
Sets or queries a horizontal cursor position in the XY display (safe operating
area).
5-69
:ANALysis:PANalyze<x>:SOA:CURSo
r:X<y>:VALue?
Sets or queries the voltage value of a horizontal cursor in the XY display (safe
operating area).
5-69
:ANALysis:PANalyze<x>:SOA:CURSo
r:Y<y>?
Queries all XY display (safe operating area) vertical cursor settings. 5-69
:ANALysis:PANalyze<x>:SOA:CURSo
r:Y<y>:POSition
Sets or queries a vertical cursor position in the XY display (safe operating
area).
5-69
:ANALysis:PANalyze<x>:SOA:CURSo
r:Y<y>:VALue?
Sets or queries the voltage value of a vertical cursor in the XY display (safe
operating area).
5-70
:ANALysis:PANalyze<x>:SOA:MODE
Sets or queries the automated measurement mode of the XY display (safe
operating area).
5-70
:ANALysis:PANalyze<x>:SOA:TRAN
ge (Time Range)
Sets or queries the range of the T-Y waveform to display in the XY display (safe
operating area).
5-70
:ANALysis:PANalyze<x>:SOA:VTDis
play
Sets or queries whether or not to display the VT waveform in the XY display
(safe operating area).
5-70
:ANALysis:PANalyze<x>:SWLoss?
Queries all switching loss settings. 5-70
:ANALysis:PANalyze<x>:SWLoss:CY
CLe
Sets or queries the on/off status of cycle mode. 5-70
:ANALysis:PANalyze<x>:SWLoss:DP
ROximal?
Queries all distal, mesial, and proximal settings. 5-70
:ANALysis:PANalyze<x>:SWLoss:DP
ROximal:MODE
Sets or queries the distal, mesial, and proximal point mode setting. 5-70
:ANALysis:PANalyze<x>:SWLoss:DP
ROximal:PERCent
Sets or queries the distal, mesial, and proximal points as percentages. 5-71
:ANALysis:PANalyze<x>:SWLoss:DP
ROximal:UNIT
Sets or queries the distal, mesial, and proximal points as voltages. 5-71
:ANALysis:PANalyze<x>:SWLoss:DT
YPe
Sets or queries the device type for total loss computation. 5-71
:ANALysis:PANalyze<x>:SWLoss:IL
EVel
Sets or queries the current level used to determine the zero loss period for
total loss computation.
5-71
:ANALysis:PANalyze<x>:SWLoss:MA
TH
Sets or queries the on/off status of the power waveform display. 5-71
:ANALysis:PANalyze<x>:SWLoss:ME
ASure?
Queries all of the settings for the automated measurement of power supply
analysis parameters.
5-71
:ANALysis:PANalyze<x>:SWLoss:ME
ASure:<Parameter>?
Queries the setting of a power supply analysis parameter. 5-71
:ANALysis:PANalyze<x>:SWLoss:ME
ASure:<Parameter>:COUNt?
Queries the continuous statistical processing count of a power supply
analysis parameter.
5-71
:ANALysis:PANalyze<x>:SWLoss:ME
ASure:<Parameter>:{MAXimum|MEAN
|MINimum|SDEViation}?
Queries a statistical value of a power supply analysis parameter. 5-72
:ANALysis:PANalyze<x>:SWLoss:ME
ASure:<Parameter>:STATe
Sets or queries the on/off status of a power supply analysis parameter. 5-72
:ANALysis:PANalyze<x>:SWLoss:ME
ASure:<Parameter>:VALue?
Queries an automatically measured value of a power supply analysis
parameter.
5-72
:ANALysis:PANalyze<x>:SWLoss:ME
Thod
Sets or queries the calculation method for high and low points. 5-72
:ANALysis:PANalyze<x>:SWLoss:RA
NGe
Sets or queries the measurement source window. 5-72
:ANALysis:PANalyze<x>:SWLoss:R
DS
Sets or queries the on-resistance value for total loss computation. 5-73
:ANALysis:PANalyze<x>:SWLoss:SC
ALe?
Queries all scaling settings. 5-73
