131
IM FG410-01EN
Sweep
Sweep type Frequency
Frequency sweep range 1 kHz to 10 kHz
Phase sweep range
-
90° to 90°
Amplitude sweep range 0.1 Vp-p to 0.2 Vp-p
DC offset sweep range
-
0.1 V to 0.1 V
Duty sweep range 40% to 60%
Sweep time 0.1 s
Sweep mode Continuous
Trigger source Internal, 1 s
External trigger input polarity Negative
Sweep function One-way, linear
Mark values 5 kHz, 0°, 0.15 Vp-p, 0 V, 50%
Stop level Off, 0%
External control input Disabled
Oscillation stop unit during gated single-shot 1 cycle
Sync/sub-output Sweep synchronization, marker on
Burst
Burst mode Trigger burst
Mark wave number 1 cycle
Space wave number 1 cycle
Trigger source Internal, 10 ms
External trigger input polarity Negative
Trigger delay 0 s
Stop level Off, 0%
Oscillation stop unit during gate 1 cycle
Sync/sub-output Burst synchronization
2-channel operation (FG420 only)
Channel mode Independent
Frequency difference 0 Hz
Frequency ratio 1:1
Same-value setting Off
Other
Use of user-defined unit Released
External 10 MHz frequency reference Disabled
External addition Off
