YOKOGAWA GX20 User Manual

2-37
IM 04L51B01-01EN
Operating the GX/GP
1
2
3
4
5
App
Index
Displaying Data File Information
You can display the memory information of the measured data that is currently displayed.
1 Press MENU.
The menu screen appears.
2 Tap the Context tab and then Data information.
The data information appears.
Display switch icons
Switch the page
Display Description
File name Data in the internal memory that has not been made into a file is
indicated as “Memory.” For data that has been made into a file, the
file name is displayed.
Data type Display data is displayed as “Display.” Event data is displayed as
“Event.”
Serial No. The serial number of the GX/GP that was used.
Batch number and lot
number
These appear when the file was created using the batch function.
Start time, End time The record start and end times.
Start user The name of the user that started recording. This appears when the
login function was used.
Stop user The name of the user that stopped recording. This appears when the
login function was used.
Comment Comment (when the batch function was used).
Text field Text field (when the batch function was used).
3 Tap Exit.
The data information screen closes.
Operation complete
Note
• When measured data on the external storage medium is displayed, the serial number
corresponds to that of the GX/GP that was used to save the data.
• When the measurement mode is set to Dual interval, custom displays do not show data
information.
2.2 Configuration of Measured Data Display
