19
All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L52B01-01EN
June. 14, 2017-00
 INPUT/OUTPUT MODULE
SPECIFICATIONS
ANALOGINPUTMODULE(Model
GX90XAorOption/Uxx0)
DIGITALINPUTMODULE(Model
GX90XDorOptions/CRx1)
DIGITALOUTPUTMODULE(Model
GX90YD,orOptions/CR1x,/CR2x,
/CR4x)
DIGITAL INPUT/OUTPUT MODULE
(ModelGX90WD)
PULSEINPUTMODULE(Model
GX90XP)
ANALOGOUTPUTMODULE(Model
GX90YA)
PIDCONTROLMODULE(Model
GX90UT)
PleaseseeGX90XA/GX90YA/GX90XD/GX90YD/
GX90WD/GX90XPInput/OutputModuleandPID
Control(GS04L53B01-31EN)GeneralSpecication
(GS 04L53B01-01EN.)
 APPLICATION SOFTWARE
SMARTDAC+STANDARD
• Universalviewer
• Hardwarecongurator(withProgrampattern
setting)
Downloadthelatestversionofthesoftwarefromthe
followingURL;
www.smartdacplus.com/software/en/
Operatingenvironment
OS:
OS Type
Windows7 HomePremiumSP1(32-bitand64-bit
Editions)
ProfessionalSP1(32-bitand64-bitEditions)
Windows8.1 Update
ProUpdate
Windows10 Home(32-bitand64-bitEditions)
Pro (32-bit and 64-bit Editions)
Processorandmainmemory:
OS Processorandmainmemory
Windows7
Windows8.1
Windows10
32-biteditionIntelPentium4,3GHzorfaster
x64orx86,2GBormore
64-biteditionIntelx64processorthatis
equivalenttoIntelPentium4,3GHzorfaster,
2GBormore
Browser:
Supportedbrowser:InternetExplorer11
HTTP1.1andJavaScriptareused.
Harddisk:
• 100MBormoreoffreespace
Display:
• AvideocardthatisrecommendedfortheOS
and a display that is supported by the OS, has a
resolutionof1024x768orhigher,andthatcan
show65,536colors(16-bit,highcolor)ormore.
UniversalViewersoftware
Theuniversalviewercandisplaythefollowingdata
generated by the recorder on the screen and print it
out on the printer.
• Displaydatale
• Eventdatale
• Reportdatale(IncludingHour,Day,Week
Month)
• Manualsampledatale
• Viewerfunction
 Waveformdisplay,digitaldisplay,circulardisplay,
list display, report display, operation log display
etc.
• Dataconversion:
 FileconversiontoASCIIorMS-Excelformat
• Signinfunction
Webapplication/Hardwarecongurator
• OnlinesettingonWebbrowser(IE)
• OfinesettingonWebbrowser(IE)
Bothsettingscanbemadeusingbrowserssuchas
InternetExplorer11.
