 MODEL AND SUFFIX CODES
Model SufxCode Optionalcode Description
GP10 Paperlessrecorder(Portabletype,Smalldisplay)
*13
GP20 Paperless recorder (Portable type, Large display)
*13
Type -1 Standard(Max.measurementchannels:100ch)
-2 Largememory(Max.measurementchannels:500ch)
*12
Displaylanguage E English,degF,DST(summer/wintertime)
*9
Power supply 1 100VAC,240VAC
*16
2 12VDC
*17
Power cord D PowercordUL/CSAstandard
F PowercordVDEstandard
R Power cord AS standard
Q Power cord BS standard
H Power cord GB standard
N Power cord NBR standard
W Screwterminal,powercordnotincluded
Optionalfeatures /AH Aerospaceheattreatment
/AS Advancedsecurityfunction(Part11)
*23
/BT Multi-batchfunction
*24
/C2 RS-232
*1
/C3 RS-422/485
*1
/CG Customdisplay
*15
/D5 VGAoutput
*2
/E1 EtherNet/IPcommunication(PLCcommunicationprotocol)
*20
/E2 WTcommunication
*14
/E3 OPC-UAserver
/E4 SLMPcommunication(MitsubishiPLC)
*21
/FL Failoutput,1point
/LG Log scale
/MT Mathematicalfunction(withreportfunction)
*18 *19
/MC Communicationchannelfunction
*21
/PG Programcontrolfunction
*25
/UH USBinterface(Host2ports)
