<7. System Delivery Precautions>
7.4.4 On-site Installation
A general procedure for on-site installation is described below.
Some systems may require other additional work to be performed. Review the state
of the existing system, and add additional work items as required.
1. Restore the control application
Decompress the delivered Logic Designer zwt file to restore the control application
on the site PC.
Rename the existing project before restoration and then restore the delivered control
application using the original name.
Other than the above restoration approach, you can also choose to either overwrite
the existing project by restoring the delivered application using the same name, or
restoring the delivered application using a different name. As a general rule, restore
the delivered application using the same name.
2. Compile and download
After restoring the control application, compile the project and then download it to
the FCN-500 or FCN-RTU in offline mode.
When downloading, include both the boot project and source.
SEE ALSO
For more details, see Section 4.9.3, “Detailed Description of Download Dialog.”
3. Start the FCN-500, FCN-RTU
After download is completed, warm start the FCN/FCJ.
If the warning message “After download no warmstart will be possible!” described in
Section 2.2.5, “Retentive Variables (Retain Data) Considerations” is displayed,
ignore the warning and proceed with download.
4. Resource Configurator Definitions
Using Resource Configurator, connect to the FCN-500 or FCN-RTU.
Add, delete or modify configuration information required for implementing the
system modification. After that, perform a download.
5. Install Duolet applictions and other applications, if any.
Install Duolet applications and other applications as required.
To Next Page
