Appendix 1 STARDOM Engineering Flow
Chart
Design Development Steps
Remove Errors
Start
Design Inputs
A
Errors
Pre-Development Arrangements
・Install Resource Configurator (RC) and Logic Designer (LD)
with suitable portfolios in Eng. Laptop
・Prepare the Stardom system and connect to Eng. Laptop
・Upgrade/Downgrade Stardom System card firmware to match
the version of Engineering Software i.e. (RC) & (LD).
・Ensure that selected IP address for Stardom is complying with
rules for duplex networking.
Stardom Resource Configuration:
・If IP address is not assigned or is unknown, reboot Stardom in
IP address setting mode and set IP address. Otherwise
connect through the known IP address.
・Set the Network Type (Single/Duplex/Separated).
・Perform settings related to the CPU module duplex for E2
Bus/SB Bus, memory backup, and use of Duolet function.
・Setup the FCX Time synchronization through SNTP settings
in JEROS files.
・Configure tags as Analog & Digital I/O as per the approved
tag list - Using Resource Configurator.
・Configure serial port parameters for Subsystems' interfaces (if
required).
・Configure IO module setting.
・Configure FF devices or Profibus devices ( if Required)
Download the Configuration
No
Yes
・
Tag List with Descriptions.
・Data Types of I/O Variables.
・Scale High & Low Ranges.
・Engineering Units
・Logic Narratives & Interlocks.
・Override Conditions
・Redundancy Conditions
・Subsystem Details.
Communication Interface
Communication Protocol
Configuration Parameters
IO Mapping Details
