<1. Overview>
1
TI 34P02K35-02E
Jun. 6, 2018-00
1. Overview
STARDOM engineering can be divided into phases as shown in the diagram
below.
Check require-
ment spec.
User acceptance
test (UAT)
System delivery
Unit test
Integration test
System test
Detailed function
design of
application
software
Check requirement
spec.
Check system
configuration
- Verify that the requirement specification can be implemented using
the STARDOM system.
- Verify that the system configuration allows implementation of the
requirement specification.
- Based on the requirement specification, prepare basic specifications
for FCN/FCJ control applications, operation/monitoring applications
and communication functions.
- Based on basic functions, perform detailed design of each
application and prepare functional specification.
- Based on function specification, create applications.
- In unit test, check individual applications.
- In integration test, combine applications already tested in unit tests
and test the integrated STARDOM system as a whole.
- In system test, combine external equipment and control panels with
the STARDOM system, and perform function test, including
communication tests.
- Verify along with customer that the designed/created application
satisfies the function specification.
- After completion of UAT, deliver STARDOM system.
FCN/FCJ control
applications
Operation and
monitoring
applications
Communication
applications
Basic design and
function design
Application creationFunction test
This engineering guide is intended as a guide for system engineering of a
STARDOM system based on given specifications. For this purpose, it describes
the precautions and checklist for each of the engineering phases after
specifications are confirmed, including basic design and function design,
application creation, function test, user acceptance test (UAT) and system
delivery.
This engineering guide focuses on FCN/FCJ control applications.
Details on the functions and use of the FCN-500 and FCN-RTU controller and
individual application programming tools can be found in their respective
instruction manuals (IM) and Technical Information (TI). Wherever necessary, this
manual will refer the reader to these documents for details on functions and
usage.
