<4. Control Application Creation>
7. Maximum value of code size in the logical POUs: 200KB
This is the upper limit on the size of one logical POU.
If the size of a logical POU exceeds 200 KB, a compiler error is generated. If the
size exceeds 80% of 200 KB, a compiler warning is displayed.
8. Maximum number of input/output parameters of the functions/function blocks:
300
9. Maximum number of logical POUs in the projects: 2000
10 Maximum number of POU instances that can be defined in project: 64000
11. Maximum number of code worksheets in the logical POUs: 255
12.Maximum number of types of available functions/function blocks in the logical
POUs: 620
13. Maximum number of available functions/function blocks in the logical POUs:
1024
14. Maximum number of jumps and labels in the logical POUs: 750
15. Maximum number of contacts/coils in the logical POUs: 3600
TIP
As the above list of system limits is not exhaustive, browse the above-mentioned online help
documentation before creating your application.
SEE ALSO
For details on the Jump function, see Section 9.1.7, “Jump, Connector and Return Functions” of
Chapter 9, “Advanced Engineering.”
For details on user-defined function blocks, see Section 4.7, “Application Encapsulation.”
