6-6
IM WT3001E-51EN
6.4 Delta Computation Specifications
Item Specifications
difference Differential voltage and differential current determined by computation
3P3W→3V3A Line voltage and phase current that are not measured but can be computed for a
three-phase, three-wire system
DELTA→STAR Line voltage and neutral line current that can be computed for a three- phase,
three-wire (3V3A) system
STAR→DELTA Neutral line voltage and neutral line current that can be computed for a three-
phase, four-wire system
