YOKOGAWA WT3002E User Manual

5-28
IM WT3001E-51EN
5.10 Ethernet Interface Specifications
Item Specifications
Number of communication ports 1
Connector type RJ-45 connector
Electrical and mechanical specifications Conforms to IEEE 802.3.
Transmission system Ethernet (100BASE-TX/10BASE-T)
Data rate 100 Mbps maximum
Communication protocol TCP/IP
Supported service FTP client
Save setup parameters, waveform display data, numeric data, and screen image
data to an FTP server (network drive) on the network. Load the setup parameters
that have been saved to the FTP server.
FTP server
Access this instrument from a PC or workstation on the network and download the
file on the PC card or USB memory in this instrument. However, an FTP client is
needed on the PC or workstation.
LPR client (network printer)
Print the screen image on a network printer.
SMTP client (mail transmission)
Periodically transmit the information of this instrument to a specified mail address.
DHCP
DNS
Remote control
This instrument can be controlled remotely from a host such as a PC. For details,
see the Communication Interface User’s Manual (IM WT3001E-17EN).
TCP Port Numbers that this instrument Uses
Port Number Description Function
20 File Transfer [Default Data] FTP server and FTP client
*
21 File Transfer [Control] FTP server and FTP client
25 Simple Mail Transfer Protocol SMTP client
515 – LPR client
10001 – Instrument control via the Ethernet interface
UDP Port Numbers that this instrument Uses
Port Number Description Function
53 Domain Name Server DNS client
67 Bootstrap Protocol Server DHCP client
68 Bootstrap Protocol Client (receive wait port)
123 Network Time Protocol SNTP client
* The port number when FTP passive mode (see section 5.9) is turned OFF. If FTP passive mode is turned ON, the port number
is arbitrary.
If FTP passive mode is OFF, connection is established from the server. If you are connecting this instrument behind a firewall,
turn FTP passive mode ON.
For the procedure of changing the FTP passive mode, see section 5.9.
