10-3
IM WT3001E-51EN
Waveform Computation (Option)
10
10.2 Various Settings Related to Waveform
Computation
A portion of the settings related to waveform computation is common with the “waveform
display in normal measurement mode” and “FFT mode.” The settings described in
sections 10.3 to 10.5 are those specific to waveform computation. Set these items first.
• Selecting the waveform computation mode Section 10.3
• Setting the waveform equation Section 10.4
•
Setting the scale, unit, and label of the computed waveform Section
10.5
The settings below are common with the waveform display of normal measurement
mode. See the respective sections below in the User’s Manual IM WT3001E-01EN.
• Selecting the waveform to be displayed Section 6.2
• Setting the time axis Section 6.3
• Setting the trigger Section 6.4
• Zooming vertically and moving the vertical position Section 6.5
• Waveform display on divided windows Section 6.6
• Selecting the display interpolation and graticule Section 6.7
• Turning ON/OFF the scale value and waveform label Section 6.8
• Cursor measurement Section 6.9
If you change settings that are common with the “waveform display in normal measurement
mode” and “FFT mode” in waveform computation mode, the waveform display settings
in normal measurement mode and FFT mode are also changed. For example, if you
change the time axis to 20 ms/division in waveform computation mode, the time axis of
the waveform display in normal measurement mode is also changed to 20 ms/division.
To Next Page
