Getting Started
4
Back of the XSLATE L10
Pen holder and pen Holds the short pen when pen is not in use
Battery latch Releases the battery latch when you slide the latch to the left
Camera light Functions as both a flash for the rear camera as well as a torch
light
Rear camera 13 megapixel camera
Kensington lock slot Provides a metal-reinforced hole for use with a cable and lock to
secure the tablet
Fan intake Where ambient air is pulled in by the fan; Do not block or cover
Fan exhaust Where heated air is exhausted by the fan; Do not block or cover
Expansion port cover Door that is removed when connecting certain accessories to the
tablet
Speaker Outputs sound when no headset or external speakers are in use
Battery Hot-swappable battery that powers the tablet when it is not
plugged in or docked
Pass-through antenna ports
(optional)
These integrated ports connect to the vehicle antenna to provide
MIMO WLAN, MIMO WWAN, and GNSS (GPS) access. This
feature must be ordered when purchased. It is factory installed.
Battery latch
Expansion
Fan intake
Fan
port cover
Speaker
Pen holder 13 megapixel
Camera light
camera
Kensington
lock slotand pen
exhaust
Battery
Antenna
pass-through
ports (optional)
RFID/NFC
(optional)
