Zebra MC93 Series Integrator Guide

Getting Started
20
13.Using a Torx T8 screwdriver with a large grip and a long shaft, secure the keypad to the device using the
two screws. Torque screws to 5.8 kgf-cm or 5.0 lbf-in.
Figure 10 Replace Keypad Screws
14.Turn the device over so that the keypad latches are visible.
15.Slide both the keypad latches toward the top of the device.
Figure 11 Slide Keypad Latches
Keypad Screws
Keypad Latches
