Getting Started
25
4. Slide the keypad latches toward the bottom of the device.
Figure 14 Release Keypad Latches
NOTE: If the keypad latches are hard to move, use a screwdriver to gently slide them towards the bottom of the device.
5. Turn the device over so that the keypad is visible.
6. Using a Torx T8 screwdriver with a large grip, remove the two keypad assembly screws from the top of the
keypad.
Figure 15 Remove Keypad
Keypad Latches
Screwdriver
microSD Card Holder
Keypad Screws
Keypad
To Next Page
