Getting Started
27
11.Slide both the keypad latches toward the top of the device.
Figure 18 Slide Keypad Latches
12.Using a Torx T8 screwdriver, replace the two keypad latch screws inside the battery slot and torque to 5.8
kgf-cm or 5.0 lbf-in.
Figure 19 Replace Keypad Latch Screws
13.Press and hold the Power key to power on the device.
