120 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Routine Maintenance
Clean Interior
Transmissive (Media) Sensor Locations
The locations of the upper and lower transmissive (media) sensors are shown in Figure 46 and
Figure 47.
Figure 46 • Upper Media Sensor
Figure 47 • Lower Media Sensor
1
Upper media sensor
1
Lower media sensor
1
1
