54 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Front Panel Controls
Front Panel LCD
MEDIA POWER UP
Media Power Up
This parameter sets the action of the labels when the printer is turned on.
• Press the right or left oval to display the choices.
Note • For best results with RFID labels, set this parameter to FEED or
LENGTH.
Default: CALIBRATION
Selections:
• FEED—feeds the labels to the first registration point.
• CALIBRATION—determines the length of the label and adjusts the sensor
settings.
• LENGTH—In continuous mode, feeds the last stored label length. In
non-continuous mode, calibrates based on the maximum label length setting
(see Setting Maximum Length on page 46).
• SHORT CAL—calibrates label length using the current sensor settings.
• NO MOTION—the media does not move. You must press
FEED to cause
the printer to resynch to the start of the next label.
HEAD CLOSE
Head Close
This parameter sets the action of the labels when the printhead is closed.
• Press the right or left oval to display the choices.
Note • For best results with RFID labels, set this parameter to FEED or
LENGTH.
Default: CALIBRATION
Selections:
• FEED—feeds the labels to the first registration point.
• CALIBRATION—determines the length of the label and adjusts the sensor
settings.
• LENGTH—In continuous mode, feeds the last stored label length. In
non-continuous mode, calibrates based on the maximum label length setting
(see Setting Maximum Length on page 46).
• SHORT CAL—calibrates label length using the current sensor settings.
• NO MOTION—the media does not move. You must press
FEED to cause
the printer to resynch to the start of the next label.
Table 7 • Standard LCD Displays (Page 11 of 16)
Parameter Action/Explanation
